EEC-S5R5V105N
RoHS
RoHS compliant
RoHS compliantPackage Axial, Can - Vertical
Category Capacitors / Electric Double Layer Capacitors (EDLC), Supercapacitors
Description
Axial Can - Vertical SG 5.5V 1F -20% +80% 0.748Lx0.217W 19.00mmx5.50mm
PDF
/
Inventory: 2026
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Dimensions
Width 5.5118mm
Length 18.9992mm
Height Seated (Max) 0.827 21.00mm
Height 5mm
Diameter 19mm
Technical
Life (Hours) 1000 hours
Leakage Current 1mA
Lifetime @ Temp 1000 Hrs @ 70°C
Voltage 5.5V
Lead Diameter 200 μm
Lead Spacing 0.197 5.00mm
ESR (Equivalent Series Resistance) 30Ohm @ 1kHz
Lead Pitch 5mm
Depth 5.5mm
Orientation Vertical
Voltage - Rated DC 5.5V
Capacitance 1F
Voltage - Rated 5.5V
Min Operating Temperature -40°C
Max Operating Temperature 70°C
Termination PC Pins
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Tolerance -20% +80%
Size / Dimension 0.748Lx0.217W 19.00mmx5.50mm
Series SG
Packaging Tray
Operating Temperature -40°C~70°C
Physical
Dielectric Material Gold
Package / Case Axial, Can - Vertical
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 14 Weeks
