EEC-S0HD223H
RoHS
RoHS compliant
RoHS compliantPackage Axial, Can - Horizontal
Category Capacitors / Electric Double Layer Capacitors (EDLC), Supercapacitors
Description
Axial Can - Horizontal ELECTRIC DOUBLE LAYER CAPACITOR SD 5.5V 22mF -20% +80% 0.413Dia 10.50mm
PDF
/
Buying Options
Total Price: USD $1.7
Unit Price: USD $1.69758
≥1 USD $1.69758
≥200 USD $0.677456
≥400 USD $0.655137
≥1000 USD $0.643321
Inventory: 4066
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 10.5mm
Length 11.5mm
Height Seated (Max) 0.217 5.50mm
Technical
Lifetime @ Temp 1000 Hrs @ 70°C
Size Code 4541
Rated (DC) Voltage (URdc) 5.5V
Lead Spacing 0.394 10.00mm
ESR (Equivalent Series Resistance) 150Ohm @ 1kHz
Capacitor Type ELECTRIC DOUBLE LAYER CAPACITOR
Reach Compliance Code unknown
Terminal Pitch 10mm
Capacitance 22mF
Additional Feature CAPACITANCE RANGE IS 0.0176F TO 0.396F
Voltage - Rated 5.5V
Terminal Finish Tin (Sn)
Termination PC Pins
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Tolerance -20% +80%
Size / Dimension 0.413Dia 10.50mm
Series SD
Published 2004
Packaging Bulk
Operating Temperature -25°C~70°C
Physical
Terminal Shape FLAT
Surface Mount NO
Package / Case Axial, Can - Horizontal
Mounting Type Through Hole
