LTP-3357AA
RoHS
/
Package DIP
Category Optoelectronics / Display Modules - LED Dot Matrix and Cluster
Description
DISPLAY DOT MTRX G, O-R 3.0" 5X7
PDF
/
Inventory: 8250
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Viewing Area (height) 7.62mm
Height 8.89mm
Technical
Internal Connection Common Anode Row, Common Cathode Column
Reverse Voltage 10V
Millicandela Rating 9.6mcd Green, 9.6mcd Orange-Red
Luminous Intensity 9.6 mcd
Test Current 20mA
Forward Current 11mA
Voltage - Forward (Vf) (Typ) 4.2V Green 4V Orange-Red
Power Dissipation 64mW
Element Configuration Common Cathode
Configuration 5 x 7
Number of Elements 35
Reach Compliance Code unknown
Depth 57mm
Number of Functions 1
HTS Code 8541.40.20.00
Color Green, Orange-Red
Min Operating Temperature -35°C
Max Operating Temperature 85°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Size / Dimension 2.24Lx3.15W x 0.35 H 56.9mmx79.9mmx8.9mm
Published 2001
Physical
Number of Pins 28
Package / Case DIP
Mount Through Hole
Supply Chain
Factory Lead Time 8 Weeks
