LTP-2657AA
RoHS
/
Package DIP
Category Optoelectronics / Display Modules - LED Dot Matrix and Cluster
Description
DISPLAY DOT MTRX G, O-R 2.0" 5X7
PDF
/
Inventory: 3767
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Viewing Area (height) 50.8mm
Height 8.636mm
Technical
Internal Connection Common Cathode Row, Common Anode Column
Peak Wavelength 630 nm
Number of Characters 1
Forward Voltage-Max 2.8V
Reverse Voltage 5V
Millicandela Rating 4.8mcd Green, 4.8mcd Orange-Red
Luminous Intensity 4.8 mcd
Test Current 20mA
Forward Current 13mA
Voltage - Forward (Vf) (Typ) 2.1V Green 2V Orange-Red
Power Dissipation 36mW
Element Configuration Common Cathode
Configuration 5 x 7
Number of Elements 70
Reach Compliance Code unknown
Depth 38mm
Number of Functions 1
Subcategory LED Displays
HTS Code 8541.40.20.00
Color Green, Orange-Red
Min Operating Temperature -35°C
Max Operating Temperature 85°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Size / Dimension 0.89Lx1.25W x 0.32 H 22.6mmx31.8mmx8.0mm
Published 2001
Physical
Number of Pins 28
Package / Case DIP
Mount Through Hole
Supply Chain
Factory Lead Time 8 Weeks
