LTP-2158AE

Lite-On Inc.
RoHS
RoHS RoHS compliant
Package DIP
Category Optoelectronics / Display Modules - LED Dot Matrix and Cluster
Description DISPLAY DOT MTRX ORN-RD 2.3" 5X8
PDF
/
Inventory: 3319
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 12 Weeks

Physical

Mount Through Hole
Package / Case DIP
Number of Pins 28

Technical

Size / Dimension 1.49Lx2.39W x 0.35 H 37.90mmx60.80mmx8.90mm
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Operating Temperature 85°C
Min Operating Temperature -25°C
Color Orange-Red
Subcategory LED Displays
Number of Functions 1
Depth 37.9mm
Reach Compliance Code unknown
Number of Elements 40
Configuration 5 x 8
Element Configuration Common Cathode
Power Dissipation 75mW
Voltage - Forward (Vf) (Typ) 2V
Forward Current 25mA
Test Current 20mA
Luminous Intensity 4.8 mcd
Reverse Voltage 5V
Forward Voltage-Max 2.8V
Number of Characters 1
Peak Wavelength 630 nm
Internal Connection Common Anode Row, Common Cathode Column

Dimensions

Height 8.89mm
Viewing Area (height) 58.42mm

Compliance

RoHS Status ROHS3 Compliant
