LTP-2157AY
RoHS
/
Package Module
Category Optoelectronics / Display Modules - LED Dot Matrix and Cluster
Description
LED MATRIX 5X7 2.0" YELLOW
PDF
/
Inventory: 8060
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Viewing Area (height) 50.8mm
Height 8.382mm
Technical
Internal Connection Common Anode Row, Common Cathode Column
Dominant Wavelength 588 nm
Peak Wavelength 585 nm
Number of Characters 1
Forward Voltage-Max 2.8V
Reverse Voltage 5V
Luminous Intensity 4.8 mcd
Test Current 20mA
Forward Current 10mA
Voltage - Forward (Vf) (Typ) 2.1V
Power Dissipation 32mW
Element Configuration Common Cathode
Configuration 5 x 7
Number of Elements 35
Reach Compliance Code unknown
Depth 38mm
Number of Functions 1
Subcategory LED Displays
HTS Code 8541.40.20.00
Color Yellow
Min Operating Temperature -35°C
Max Operating Temperature 85°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Size / Dimension 1.50Lx2.09W x 0.34 H 38.1mmx53.1mmx8.6mm
Published 2000
Physical
Number of Pins 14
Package / Case Module
Mount Through Hole
Supply Chain
Factory Lead Time 8 Weeks
