LTP-2157AHR
RoHS
RoHS compliant
RoHS compliantPackage DIP
Category Optoelectronics / Display Modules - LED Dot Matrix and Cluster
Description
LED MATRIX 5X7 2.0" HI-EFF RED
PDF
/
Inventory: 1531
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Viewing Area (height) 50.8mm
Height 8.382mm
Technical
Internal Connection Common Anode Row, Common Cathode Column
Dominant Wavelength 623 nm
Number of Characters 1
Forward Voltage-Max 2.8V
Reverse Voltage 5V
Display Type Dot Matrix
Luminous Intensity 4.8 mcd
Test Current 20mA
Forward Current 13mA
Voltage - Forward (Vf) (Typ) 2V
Power Dissipation 36mW
Element Configuration Common Cathode
Configuration 5 x 7
Number of Elements 35
Reach Compliance Code not_compliant
Depth 38mm
Number of Functions 1
Subcategory LED Displays
HTS Code 8541.40.20.00
Color Red
Min Operating Temperature -35°C
Max Operating Temperature 85°C
Terminal Finish Tin/Lead (Sn/Pb)
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e0
Size / Dimension 1.50Lx2.09W x 0.34 H 38.1mmx53.1mmx8.6mm
Published 2000
Physical
Number of Pins 14
Package / Case DIP
Mount Through Hole
Supply Chain
Factory Lead Time 12 Weeks
