TBC20-11EGWA
RoHS
RoHS compliant
RoHS compliantPackage /
Category Optoelectronics / Display Modules - LED Dot Matrix and Cluster
Description
LED Displays & Accessories RED/GREEN DIFFUSED 5X7 DOT MATRIX
PDF
/
Inventory: 7942
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Character Height 50mm
Width 53.086mm
Length 38.1mm
Height 8.382mm
Technical
Internal Connection Common Anode Row, Common Cathode Column
Peak Wavelength 627 nm
Wavelength 568 nm
Illumination Color Green, Red
Millicandela Rating 15mcd Green, 10mcd Red
Luminous Intensity 16 mcd
Forward Voltage 2.2V
Forward Current 25mA
Voltage - Forward (Vf) (Typ) 2.2V Green 2V Red
Element Configuration Common Cathode
Configuration 5 x 7
Operating Supply Voltage 2.2V
Voltage - Rated DC 2.2V
Color Green, Red
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 1.50Lx2.09W x 0.33 H 38.1mmx53.1mmx8.5mm
Published 2003
Supply Chain
Factory Lead Time 8 Weeks
