HDSP-703G
RoHS
RoHS compliant
RoHS compliantPackage DIP
Category Optoelectronics / Display Modules - LED Dot Matrix and Cluster
Description
LED Displays & Accessories Green 573nm 0.68in 5x7 Dot Matrix
PDF
/
Buying Options
Total Price: USD $4.63
Unit Price: USD $4.6288
≥1 USD $4.6288
≥10 USD $3.27536
≥100 USD $2.682944
≥500 USD $2.261776
≥1000 USD $2.074591
≥3000 USD $1.9888
Inventory: 1157
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Viewing Area (height) 17.27mm
Height 6.35mm
Technical
Internal Connection Common Cathode Row, Common Anode Column
Dominant Wavelength 573 nm
Number of Characters 1
Wavelength 573 nm
Reverse Voltage 5V
Millicandela Rating 960μcd ~ 7.28mcd
Luminous Intensity 7.28 mcd
Test Current 50mA
Forward Current 15mA
Power Dissipation 75mW
Element Configuration Common Cathode
Configuration 5 x 7
Number of Elements 35
Operating Supply Voltage 2.25V
Depth 12.7mm
Number of Functions 1
Subcategory LED Displays
HTS Code 8531.20.00.40
Color Green
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Terminal Finish Tin (Sn)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Size / Dimension 0.70Lx0.50W x 0.25 H 17.80mmx12.70mmx6.30mm
Series HDSP-70xG
Published 2011
Physical
Number of Pins 12
Package / Case DIP
Mount Through Hole
Supply Chain
Factory Lead Time 16 Weeks
