HDSP-2534
RoHS
RoHS compliant
RoHS compliantPackage DIP
Category Optoelectronics / Display Modules - LED Dot Matrix and Cluster
Description
AVAGO TECHNOLOGIES HDSP-2534 LED DISPLAY, ALPHANUMERIC
PDF
/
Buying Options
Total Price: USD $85.36
Unit Price: USD $85.3632
≥1 USD $85.3632
≥10 USD $82.60915
≥100 USD $79.8551
≥500 USD $71.59485
Inventory: 15
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Contact Plating Copper, Tin
Mount Through Hole
Package / Case DIP
Number of Pins 24
Technical
Published 2008
Series HDSP-253x
Size / Dimension 1.69Lx0.45W x 0.21 H 42.93mmx11.43mmx5.31mm
JESD-609 Code e2
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Terminal Finish Tin/Copper (Sn/Cu)
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Color Red
Additional Feature TTL COMPATIBLE
HTS Code 8531.20.00.40
Subcategory LED Displays
Voltage - Rated DC 5V
Number of Functions 8
Depth 11.43mm
Operating Supply Voltage 5V
Number of Elements 280
Configuration 5 x 7
Interface Parallel, 8-Bit
Max Supply Voltage 5.5V
Min Supply Voltage 4.5V
Forward Current 330mA
Forward Voltage 5V
Luminous Intensity 25 mcd
Wavelength - Peak 645 nm
Number of Characters 8
Dominant Wavelength 637 nm
Dimensions
Height 5.334mm
Viewing Area (height) 4.57mm
Character Height 4.57mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
