HDSP-2530
RoHS
RoHS compliant
RoHS compliantPackage DIP
Category Optoelectronics / Display Modules - LED Dot Matrix and Cluster
Description
Alphanumeric Displays Panel 8DIGIT 280LED Orange 24-Pin DIP Tube
PDF
/
Buying Options
Total Price: USD $103.4
Unit Price: USD $103.401378
≥1 USD $103.401378
≥200 USD $41.257883
≥500 USD $39.879338
≥1000 USD $39.197942
Inventory: 7773
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 5 Weeks
Physical
Mount Through Hole
Package / Case DIP
Number of Pins 24
Technical
Packaging Rail/Tube
Published 2014
Series HDSP-253x
Size / Dimension 1.69Lx0.45W x 0.21 H 42.93mmx11.43mmx5.31mm
JESD-609 Code e2
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Terminal Finish Tin/Copper (Sn/Cu)
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Color Orange
Additional Feature TTL COMPATIBLE
HTS Code 8531.20.00.40
Subcategory LED Displays
Voltage - Rated DC 5V
Number of Functions 8
Depth 11.43mm
Operating Supply Voltage 5V
Number of Elements 280
Configuration 5 x 7
Interface Parallel, 8-Bit
Max Supply Voltage 5.5V
Min Supply Voltage 4.5V
Forward Current 370mA
Forward Voltage 5V
Luminous Intensity 7.5 mcd
Millicandela Rating 2.50mcd ~ 20.28mcd
Wavelength - Peak 600 nm
Number of Characters 8
Dominant Wavelength 602 nm
Dimensions
Height 5.334mm
Viewing Area (height) 4.57mm
Character Height 5mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
