HDSP-2504

Broadcom Limited
RoHS
RoHS RoHS compliant
Package DIP
Category Optoelectronics / Display Modules - LED Dot Matrix and Cluster
Description Alphanumeric Displays Panel 8DIGIT 280LED Red 28-Pin DIP Tube
PDF
/
Buying Options
Total Price: USD $186.15
Unit Price: USD $186.148214
≥1 USD $186.148214
≥200 USD $74.274692
≥500 USD $71.793311
≥1000 USD $70.567062
Inventory: 1601
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 5 Weeks

Physical

Mount Through Hole
Package / Case DIP
Number of Pins 28

Technical

Series HDSP-250x
Size / Dimension 2.79Lx0.76W x 0.26 H 70.87mmx19.41mmx6.60mm
JESD-609 Code e2
Part Status Active
Moisture Sensitivity Level (MSL) 2A (4 Weeks)
ECCN Code EAR99
Terminal Finish Tin/Copper (Sn/Cu)
Max Operating Temperature 85°C
Min Operating Temperature -45°C
Color Red
Additional Feature TTL COMPATIBLE
HTS Code 8531.20.00.40
Subcategory LED Displays
Voltage - Rated DC 5V
Number of Functions 1
Depth 19.58mm
Number of Elements 280
Configuration 5 x 7
Interface Parallel, 8-Bit
Max Supply Voltage 5.5V
Min Supply Voltage 4.5V
Forward Voltage 5V
Luminous Intensity 15 mcd
Millicandela Rating 7.68mcd ~ 45.63mcd
Wavelength - Peak 645 nm
Number of Characters 8
Dominant Wavelength 637 nm

Dimensions

Height 6.604mm
Character Height 6.86mm

Compliance

RoHS Status ROHS3 Compliant
Lead Free Lead Free
