HDSP-2502

Broadcom Limited
RoHS
RoHS RoHS compliant
Package DIP
Category Optoelectronics / Display Modules - LED Dot Matrix and Cluster
Description AVAGO TECHNOLOGIES HDSP-2502 LED DISPLAY, ALPHANUMERIC
PDF
/
Inventory: /
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No

Dimensions

Character Height 6.96mm
Height 6.604mm

Technical

Character Width 5.08mm
Dominant Wavelength 626 nm
Number of Characters 8
Wavelength - Peak 635 nm
Luminous Intensity 7.5 mcd
Forward Voltage 5V
Forward Current 300mA
Min Supply Voltage 4.5V
Max Supply Voltage 5.5V
Interface Parallel, 8-Bit
Configuration 5 x 7
Number of Elements 280
Operating Supply Voltage 5V
Depth 19.58mm
Number of Functions 1
Voltage - Rated DC 5V
Subcategory LED Displays
Additional Feature TTL COMPATIBLE
Color Red
Min Operating Temperature -45°C
Max Operating Temperature 85°C
Terminal Finish Tin/Copper (Sn/Cu)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e2
Size / Dimension 2.79Lx0.76W x 0.26 H 70.87mmx19.41mmx6.60mm
Series HDSP-250x
Published 2008

Physical

Number of Pins 28
Package / Case DIP
Mount Through Hole

Supply Chain

Factory Lead Time 16 Weeks
