HDSP-2132

Broadcom Limited
RoHS
RoHS RoHS compliant
Package DIP
Category Optoelectronics / Display Modules - LED Dot Matrix and Cluster
Description DISPLAY 5X7 8DIGIT .2" 32DIP RED
PDF
/
Buying Options
Total Price: USD $241.09
Unit Price: USD $241.09195
≥1 USD $241.09195
≥10 USD $216.1516
Inventory: 706
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No

Dimensions

Character Height 5mm
Viewing Area (height) 4.83mm
Height 6.35mm

Technical

Dominant Wavelength 626 nm
Number of Characters 8
Display Type Dot Matrix
Wavelength - Peak 635 nm
Millicandela Rating 2.50mcd ~ 20.28mcd
Luminous Intensity 7.5 mcd
Forward Voltage 5V
Min Supply Voltage 4.5V
Max Supply Voltage 5.5V
Interface Parallel, 8-Bit
Configuration 5 x 7
Number of Elements 280
Operating Supply Voltage 5V
Depth 9.91mm
Number of Functions 8
Voltage - Rated DC 5V
Subcategory LED Displays
HTS Code 8531.20.00.40
Additional Feature TTL COMPATIBLE
Color Red
Min Operating Temperature -55°C
Max Operating Temperature 85°C
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e1
Size / Dimension 1.68Lx0.39W x 0.25 H 42.72mmx9.91mmx6.35mm
Series HDSP-213x
Published 2007
Packaging Rail/Tube

Physical

Number of Pins 24
Package / Case DIP
Mount Through Hole

Supply Chain

Factory Lead Time 9 Weeks
