HDSP-2107
RoHS
RoHS compliant
RoHS compliantPackage DIP
Category Optoelectronics / Display Modules - LED Dot Matrix and Cluster
Description
Alphanumeric Displays Panel 8DIGIT 280LED Red 28-Pin DIP Tube
PDF
/
Buying Options
Total Price: USD $114.43
Unit Price: USD $114.433677
≥1 USD $114.433677
≥200 USD $45.660036
≥500 USD $44.134446
≥1000 USD $43.380842
Inventory: 5950
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Character Height 5.08mm
Viewing Area (height) 6.96mm
Height 5.334mm
Technical
Dominant Wavelength 637 nm
Number of Characters 8
Wavelength - Peak 645 nm
Millicandela Rating 5.12mcd ~ 45.63mcd
Luminous Intensity 15 mcd
Forward Voltage 5V
Min Supply Voltage 4.5V
Max Supply Voltage 5.5V
Interface Parallel, 8-Bit
Configuration 5 x 7
Number of Elements 280
Depth 19.58mm
Number of Functions 1
Voltage - Rated DC 5V
Subcategory LED Displays
HTS Code 8531.20.00.40
Additional Feature TTL COMPATIBLE
Color Red
Min Operating Temperature -45°C
Max Operating Temperature 85°C
Terminal Finish Tin/Copper (Sn/Cu)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e2
Size / Dimension 1.68Lx0.77W x 0.21 H 42.59mmx19.58mmx5.31mm
Series HDSP-210x
Published 2013
Physical
Number of Pins 28
Package / Case DIP
Mount Through Hole
Supply Chain
Factory Lead Time 16 Weeks
