HDLY-2416

Broadcom Limited
RoHS
RoHS RoHS compliant
Package DIP
Category Optoelectronics / Display Modules - LED Dot Matrix and Cluster
Description LED DISPLAY 5X7 5MM 4CHAR YELLOW
PDF
/
Buying Options
Total Price: USD $239.64
Unit Price: USD $239.6413
≥1 USD $239.6413
≥10 USD $214.85105
Inventory: 706
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 16 Weeks

Physical

Mount Through Hole
Package / Case DIP
Number of Pins 18

Technical

Published 2011
Series HDLx-2416
Size / Dimension 0.99Lx0.79W x 0.26 H 25.15mmx20.07mmx6.60mm
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Dominant Wavelength 585 nm
Number of Characters 4
Wavelength - Peak 583 nm
Luminous Intensity 3.7 mcd
Forward Voltage 5V
Forward Current 110mA
Min Supply Voltage 4.5V
Max Supply Voltage 5.5V
Interface 7-Bit ASCII
Configuration 5 x 7
Number of Elements 140
Operating Supply Voltage 5V
Depth 20.07mm
Number of Functions 4
Voltage - Rated DC 5V
Subcategory LED Displays
HTS Code 8531.20.00.40
Additional Feature BUILT-IN MEMORY, WITH DECODER/DRIVER
Color Yellow
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Terminal Finish Tin (Sn)
ECCN Code EAR99

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No

Dimensions

Character Height 5mm
Viewing Area (height) 5.08mm
Height 6.604mm
