HDLS-2416
RoHS
RoHS compliant
RoHS compliantPackage DIP
Category Optoelectronics / Display Modules - LED Dot Matrix and Cluster
Description
DISPLAY 5X7 0.2" 4CHAR SUN.VIEW
PDF
/
Buying Options
Total Price: USD $35.75
Unit Price: USD $35.7544
≥1 USD $35.7544
≥10 USD $27.9994
≥100 USD $24.457312
Inventory: 206
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mount Through Hole
Package / Case DIP
Number of Pins 18
Technical
Packaging Rail/Tube
Published 2012
Series HDLx-2416
Size / Dimension 0.99Lx0.79W x 0.26 H 25.15mmx20.07mmx6.60mm
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Terminal Finish Tin (Sn)
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Color Red
Additional Feature BUILT-IN MEMORY, WITH DECODER/DRIVER
HTS Code 8531.20.00.40
Subcategory LED Displays
Voltage - Rated DC 5V
Number of Functions 4
Depth 20.07mm
Number of Elements 140
Configuration 5 x 7
Interface 7-Bit ASCII
Max Supply Voltage 5.5V
Min Supply Voltage 4.5V
Forward Voltage 5V
Luminous Intensity 12.7 mcd
Millicandela Rating 3.97mcd ~ 36.49mcd
Wavelength - Peak 645 nm
Number of Characters 4
Dominant Wavelength 637 nm
Dimensions
Height 6.604mm
Viewing Area (height) 5.08mm
Character Height 5mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
