HDLO-2416
RoHS
RoHS compliant
RoHS compliantPackage DIP
Category Optoelectronics / Display Modules - LED Dot Matrix and Cluster
Description
AVAGO TECHNOLOGIES HDLO-2416 LED DISPLAY, ALPHANUMERIC
PDF
/
Buying Options
Total Price: USD $34.06
Unit Price: USD $34.056
≥1 USD $34.056
≥10 USD $26.6684
≥100 USD $23.294744
Inventory: 1213
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Character Height 5mm
Viewing Area (height) 5.08mm
Height 6.854mm
Technical
Character Width 3.43mm
Dominant Wavelength 626 nm
Ambient Temperature Range High 85°C
Max Junction Temperature (Tj) 150°C
Number of Characters 4
Display Type Dot Matrix
Wavelength - Peak 635 nm
Luminous Intensity 3.5 mcd
Forward Voltage 5V
Forward Current 110mA
Viewing Angle 50 °
Min Supply Voltage 4.5V
Max Supply Voltage 5.5V
Interface 7-Bit ASCII
Configuration 5 x 7
Number of Elements 140
Operating Supply Voltage 5V
Depth 20.07mm
Number of Functions 4
Voltage - Rated DC 5V
Subcategory LED Displays
Additional Feature BUILT-IN MEMORY, WITH DECODER/DRIVER
Color Red
Min Operating Temperature -40°C
Max Operating Temperature 85°C
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Size / Dimension 0.99Lx0.79W x 0.26 H 25.15mmx20.07mmx6.60mm
Series HDLx-2416
Published 2008
Physical
Number of Pins 18
Package / Case DIP
Mount Through Hole
Contact Plating Tin
Supply Chain
Factory Lead Time 16 Weeks
