HDLA-1414

Broadcom Limited
RoHS
RoHS RoHS compliant
Package DIP
Category Optoelectronics / Display Modules - LED Dot Matrix and Cluster
Description Alphanumeric Displays Panel 4DIGIT 140LED Orange 12-Pin DIP
PDF
/
Buying Options
Total Price: USD $33.29
Unit Price: USD $33.2904
≥1 USD $33.2904
≥10 USD $26.067712
≥100 USD $22.77
Inventory: 215
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 16 Weeks

Physical

Mount Through Hole
Package / Case DIP
Number of Pins 12

Technical

Series HDLx-1414
Size / Dimension 0.70Lx0.79W x 0.24 H 17.66mmx20.12mmx6.10mm
JESD-609 Code e2
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Terminal Finish Tin/Copper (Sn/Cu)
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Color Orange
HTS Code 8531.20.00.40
Subcategory LED Displays
Voltage - Rated DC 5V
Number of Functions 4
Depth 17.66mm
Operating Supply Voltage 5V
Number of Elements 140
Configuration 5 x 7
Interface 7-Bit ASCII
Max Supply Voltage 5.5V
Min Supply Voltage 4.5V
Forward Current 160mA
Forward Voltage 5V
Luminous Intensity 3.5 mcd
Millicandela Rating 1.20mcd ~ 13.30mcd
Wavelength - Peak 600 nm
Number of Characters 4
Dominant Wavelength 602 nm

Dimensions

Height 6.096mm
Viewing Area (height) 3.61mm
Character Height 3.7mm

Compliance

RoHS Status ROHS3 Compliant
Lead Free Lead Free
