HCMS-3972
RoHS
RoHS compliant
RoHS compliantPackage DIP
Category Optoelectronics / Display Modules - LED Dot Matrix and Cluster
Description
LED Displays & Accessories Red 626nm 1x8 Alphanumeric
PDF
/
Buying Options
Total Price: USD $45.28
Unit Price: USD $45.276
≥1 USD $45.276
≥10 USD $35.36984
≥100 USD $33.600952
Inventory: 245
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mount Through Hole
Package / Case DIP
Number of Pins 14
Technical
Published 2010
Series HCMS-39xx
Size / Dimension 1.69Lx0.45W x 0.21 H 42.93mmx11.43mmx5.31mm
Character Width 2.54mm
Dominant Wavelength 628 nm
Number of Characters 8
Power Consumption 1.532W
Wavelength - Peak 641 nm
Millicandela Rating 128μcd
Luminous Intensity 128 mcd
Forward Voltage 3.3V
Forward Current 10mA
Power Dissipation 1.532W
Element Configuration Common Cathode
Min Supply Voltage 3.1V
Max Supply Voltage 5.5V
Interface Serial
Configuration 5 x 7
Number of Elements 280
Operating Supply Voltage 3.3V
Depth 11.43mm
Number of Functions 8
Voltage - Rated DC 3.3V
Subcategory LED Displays
Additional Feature TTL COMPATIBLE
Color Red
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Terminal Finish Tin/Copper (Sn/Cu)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e2
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Character Height 5.08mm
Viewing Area (height) 4.57mm
Height 5.334mm
