HCMS-3966

Broadcom Limited
RoHS
RoHS RoHS compliant
Package DIP
Category Optoelectronics / Display Modules - LED Dot Matrix and Cluster
Description LED Displays & Accessories Red 624nm 1x4 Alphanumeric
PDF
/
Buying Options
Total Price: USD $69.7
Unit Price: USD $69.697242
≥1 USD $69.697242
≥10 USD $27.810558
≥100 USD $26.881317
≥500 USD $26.421558
Inventory: 3821
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 16 Weeks

Physical

Mount Through Hole
Package / Case DIP
Number of Pins 12

Technical

Published 2010
Series HCMS-39xx
Size / Dimension 0.85Lx0.45W x 0.21 H 21.46mmx11.43mmx5.31mm
JESD-609 Code e2
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Terminal Finish Tin/Copper (Sn/Cu)
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Color Red
Additional Feature TTL COMPATIBLE
Subcategory LED Displays
Voltage - Rated DC 3.3V
Number of Functions 1
Depth 11.43mm
Operating Supply Voltage 3.3V
Number of Elements 140
Configuration 5 x 7
Interface Serial
Max Supply Voltage 5.5V
Min Supply Voltage 3.1V
Element Configuration Common Cathode
Power Dissipation 766mW
Forward Current 5mA
Forward Voltage 3.3V
Luminous Intensity 2.3 mcd
Wavelength - Peak 635 nm
Power Consumption 766mW
Number of Characters 4
Dominant Wavelength 624 nm
Character Width 2.54mm

Dimensions

Height 5.334mm
Viewing Area (height) 4.57mm
Character Height 5.08mm

Compliance

RoHS Status ROHS3 Compliant
Lead Free Lead Free
