HCMS-3963

Broadcom Limited
RoHS
RoHS RoHS compliant
Package DIP
Category Optoelectronics / Display Modules - LED Dot Matrix and Cluster
Description Alphanumeric Displays Panel 4DIGIT 140LED Green 12-Pin DIP
PDF
/
Inventory: 1635
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 5 Weeks

Physical

Mount Through Hole
Package / Case DIP
Number of Pins 12

Technical

Series HCMS-39xx
Size / Dimension 0.85Lx0.45W x 0.21 H 21.46mmx11.43mmx5.31mm
JESD-609 Code e2
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Terminal Finish TIN COPPER/TIN SILVER
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Color Green
Voltage - Rated 3.3V
Additional Feature TTL COMPATIBLE
HTS Code 8531.20.00.40
Voltage - Rated DC 3.3V
Number of Functions 4
Depth 11.43mm
Number of Elements 140
Configuration 5 x 7
Interface Serial
Max Supply Voltage 5.5V
Min Supply Voltage 3.1V
Element Configuration Common Cathode
Power Dissipation 766mW
Forward Current 400μA
Forward Voltage 3.3V
Luminous Intensity 252 μcd
Wavelength - Peak 568 nm
Dominant Wavelength 574 nm

Dimensions

Height 5.334mm
Viewing Area (height) 4.57mm
Character Height 5.08mm

Compliance

Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
