HCMS-3917

Broadcom Limited
RoHS
RoHS RoHS compliant
Package DIP
Category Optoelectronics / Display Modules - LED Dot Matrix and Cluster
Description Alphanumeric Displays Panel 8DIGIT 280LED Green 14-Pin DIP
PDF
/
Buying Options
Total Price: USD $46.39
Unit Price: USD $46.3936
≥1 USD $46.3936
≥10 USD $36.2428
≥100 USD $34.43088
Inventory: 298
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No

Dimensions

Character Height 3.81mm
Viewing Area (height) 3.71mm
Height 5.08mm

Technical

Character Width 2.11mm
Dominant Wavelength 572 nm
Number of Characters 8
Wavelength - Peak 574 nm
Luminous Intensity 1 mcd
Forward Voltage 3.3V
Power Dissipation 1.532W
Element Configuration Common Cathode
Min Supply Voltage 3.1V
Max Supply Voltage 5.5V
Interface Serial
Configuration 5 x 7
Number of Elements 280
Operating Supply Voltage 3.3V
Depth 10.16mm
Number of Functions 1
Voltage - Rated DC 3.3V
Subcategory LED Displays
Additional Feature TTL COMPATIBLE
Color Green
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Terminal Finish Tin/Copper (Sn/Cu)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e2
Size / Dimension 1.40Lx0.40W x 0.20 H 35.56mmx10.16mmx5.08mm
Series HCMS-39xx
Published 2010

Physical

Number of Pins 14
Package / Case DIP
Mount Through Hole
Contact Plating Copper, Tin

Supply Chain

Factory Lead Time 16 Weeks
