HCMS-3916
RoHS
RoHS compliant
RoHS compliantPackage DIP
Category Optoelectronics / Display Modules - LED Dot Matrix and Cluster
Description
Alphanumeric Displays Panel 8DIGIT 280LED Red 14-Pin DIP
PDF
/
Buying Options
Total Price: USD $54.59
Unit Price: USD $54.5864
≥1 USD $54.5864
≥10 USD $45.2232
≥100 USD $43.636384
Inventory: 198
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Character Height 3.81mm
Viewing Area (height) 3.71mm
Height 5.08mm
Technical
Dominant Wavelength 624 nm
Number of Characters 8
Power Consumption 1.532W
Wavelength - Peak 635 nm
Luminous Intensity 2.3 mcd
Forward Voltage 3.3V
Forward Current 10mA
Power Dissipation 1.532W
Element Configuration Common Cathode
Min Supply Voltage 3.1V
Max Supply Voltage 5.5V
Interface Serial
Configuration 5 x 7
Number of Elements 280
Operating Supply Voltage 3.3V
Depth 10.16mm
Number of Functions 1
Voltage - Rated DC 3.3V
Subcategory LED Displays
HTS Code 8531.20.00.40
Additional Feature TTL COMPATIBLE
Color Red
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Terminal Finish Tin/Copper (Sn/Cu)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e2
Size / Dimension 1.40Lx0.40W x 0.20 H 35.56mmx10.16mmx5.08mm
Series HCMS-39xx
Published 2011
Physical
Number of Pins 14
Package / Case DIP
Mount Through Hole
Supply Chain
Factory Lead Time 16 Weeks
