HCMS-3914
RoHS
RoHS compliant
RoHS compliantPackage DIP
Category Optoelectronics / Display Modules - LED Dot Matrix and Cluster
Description
Alphanumeric Displays Panel 8DIGIT 280LED Orange 14-Pin DIP
PDF
/
Buying Options
Total Price: USD $104.12
Unit Price: USD $104.124786
≥1 USD $104.124786
≥200 USD $41.546721
≥500 USD $40.158985
≥1000 USD $39.472339
Inventory: 6001
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mount Through Hole
Package / Case DIP
Number of Pins 14
Technical
Series HCMS-39xx
Size / Dimension 1.40Lx0.40W x 0.20 H 35.56mmx10.16mmx5.08mm
JESD-609 Code e2
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Terminal Finish Tin/Copper (Sn/Cu)
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Color Orange
Additional Feature TTL COMPATIBLE
Subcategory LED Displays
Voltage - Rated DC 3.3V
Number of Functions 8
Depth 10.16mm
Number of Elements 280
Configuration 5 x 7
Interface Serial
Max Supply Voltage 5.5V
Min Supply Voltage 3.1V
Element Configuration Common Cathode
Power Dissipation 1.532W
Forward Voltage 3.3V
Luminous Intensity 130 μcd
Millicandela Rating 128μcd
Wavelength - Peak 592 nm
Number of Characters 8
Dominant Wavelength 588 nm
Character Width 2.11mm
Dimensions
Height 5.08mm
Viewing Area (height) 3.71mm
Character Height 3.81mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
