HCMS-3912

Broadcom Limited
RoHS
RoHS RoHS compliant
Package DIP
Category Optoelectronics / Display Modules - LED Dot Matrix and Cluster
Description Alphanumeric Displays Panel 8DIGIT 280LED Red 14-Pin DIP
PDF
/
Buying Options
Total Price: USD $85.31
Unit Price: USD $85.30699
≥1 USD $85.30699
≥200 USD $34.038245
≥500 USD $32.901274
≥1000 USD $32.339353
Inventory: 1128
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant

Dimensions

Character Height 3.81mm
Viewing Area (height) 3.71mm
Height 5.08mm

Technical

Character Width 2.11mm
Dominant Wavelength 628 nm
Number of Characters 8
Wavelength - Peak 641 nm
Millicandela Rating 128μcd
Luminous Intensity 130 μcd
Forward Voltage 3.3V
Power Dissipation 1.532W
Element Configuration Common Cathode
Min Supply Voltage 3.1V
Max Supply Voltage 5.5V
Interface Serial
Configuration 5 x 7
Number of Elements 280
Depth 10.16mm
Number of Functions 8
Voltage - Rated DC 3.3V
Subcategory LED Displays
Additional Feature TTL COMPATIBLE
Color Red
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Terminal Finish Tin/Copper (Sn/Cu)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e2
Size / Dimension 1.40Lx0.40W x 0.20 H 35.56mmx10.16mmx5.08mm
Series HCMS-39xx
Published 2010

Physical

Number of Pins 14
Package / Case DIP
Mount Through Hole

Supply Chain

Factory Lead Time 16 Weeks
