HCMS-3903

Broadcom Limited
RoHS
RoHS RoHS compliant
Package DIP
Category Optoelectronics / Display Modules - LED Dot Matrix and Cluster
Description AVAGO TECHNOLOGIES HCMS-3903 LED DISPLAY, 4 CHAR, 0.15", GREEN
PDF
/
Buying Options
Total Price: USD $57.67
Unit Price: USD $57.665194
≥1 USD $57.665194
≥200 USD $23.008573
≥500 USD $22.240526
≥1000 USD $21.859785
Inventory: 3774
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC

Dimensions

Character Height 3.81mm
Viewing Area (height) 3.71mm
Height 5.08mm

Technical

Character Width 2.11mm
Dominant Wavelength 574 nm
Number of Characters 4
Power Consumption 766mW
Wavelength - Peak 568 nm
Luminous Intensity 252 μcd
Forward Voltage 3.3V
Forward Current 400μA
Power Dissipation 766mW
Element Configuration Common Cathode
Min Supply Voltage 3.1V
Max Supply Voltage 5.5V
Interface Serial
Configuration 5 x 7
Number of Elements 140
Operating Supply Voltage 3.3V
Depth 10.16mm
Number of Functions 4
Voltage - Rated DC 3.3V
Additional Feature TTL COMPATIBLE
Color Green
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Terminal Finish TIN COPPER/TIN SILVER
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e2
Size / Dimension 0.70Lx0.40W x 0.20 H 17.8mmx10.2mmx5.1mm
Series HCMS-39xx
Published 2006

Physical

Number of Pins 12
Package / Case DIP
Mount Through Hole
Contact Plating Copper, Tin

Supply Chain

Factory Lead Time 16 Weeks
