HCMS-3902
RoHS
RoHS compliant
RoHS compliantPackage DIP
Category Optoelectronics / Display Modules - LED Dot Matrix and Cluster
Description
Alphanumeric Displays Panel 4DIGIT 140LED Red 12-Pin DIP
PDF
/
Buying Options
Total Price: USD $36.24
Unit Price: USD $36.2384
≥1 USD $36.2384
≥10 USD $28.31312
≥100 USD $26.897552
Inventory: 325
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 5 Weeks
Physical
Mount Through Hole
Package / Case DIP
Number of Pins 12
Technical
Published 2010
Series HCMS-39xx
Size / Dimension 0.70Lx0.40W x 0.20 H 17.8mmx10.2mmx5.1mm
JESD-609 Code e2
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Terminal Finish Tin/Copper (Sn/Cu)
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Color Red
Additional Feature TTL COMPATIBLE
Subcategory LED Displays
Voltage - Rated DC 3.3V
Number of Functions 4
Depth 10.16mm
Number of Elements 140
Configuration 5 x 7
Interface Serial
Max Supply Voltage 5.5V
Min Supply Voltage 3.1V
Element Configuration Common Cathode
Power Dissipation 766mW
Forward Voltage 3.3V
Luminous Intensity 128 mcd
Millicandela Rating 128μcd
Wavelength - Peak 641 nm
Number of Characters 4
Dominant Wavelength 628 nm
Character Width 2.11mm
Dimensions
Height 5.08mm
Viewing Area (height) 3.71mm
Character Height 3.81mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
