HCMS-3901

Broadcom Limited
RoHS
RoHS RoHS compliant
Package DIP
Category Optoelectronics / Display Modules - LED Dot Matrix and Cluster
Description Alphanumeric Displays Panel 4DIGIT 140LED Yellow 12-Pin DIP
PDF
/
Buying Options
Total Price: USD $57.61
Unit Price: USD $57.611365
≥1 USD $57.611365
≥200 USD $22.987566
≥500 USD $22.21952
≥1000 USD $21.840092
Inventory: 5593
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 5 Weeks

Physical

Mount Through Hole
Package / Case DIP
Number of Pins 12

Technical

Series HCMS-39xx
Size / Dimension 0.70Lx0.40W x 0.20 H 17.8mmx10.2mmx5.1mm
JESD-609 Code e2
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Terminal Finish TIN COPPER/TIN SILVER
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Color Yellow
Additional Feature TTL COMPATIBLE
HTS Code 8531.20.00.40
Voltage - Rated DC 3.3V
Number of Functions 4
Depth 10.16mm
Number of Elements 140
Configuration 5 x 7
Interface Serial
Max Supply Voltage 5.5V
Min Supply Voltage 3.1V
Element Configuration Common Cathode
Power Dissipation 766mW
Forward Voltage 3.3V
Luminous Intensity 148 μcd
Wavelength - Peak 583 nm
Dominant Wavelength 585 nm

Dimensions

Height 5.08mm
Viewing Area (height) 3.71mm
Character Height 3.81mm

Compliance

RoHS Status ROHS3 Compliant
Lead Free Lead Free
