HCMS-2962
RoHS
RoHS compliant
RoHS compliantPackage DIP
Category Optoelectronics / Display Modules - LED Dot Matrix and Cluster
Description
LED DISPLAY 5X7 4CHAR 5MM HER
PDF
/
Buying Options
Total Price: USD $32.24
Unit Price: USD $32.2432
≥1 USD $32.2432
≥10 USD $25.24456
≥100 USD $22.050776
Inventory: 1134
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Viewing Area (height) 4.57mm
Height 5.334mm
Technical
Dominant Wavelength 626 nm
Number of Characters 4
Wavelength 626 nm
Display Type Dot Matrix
Millicandela Rating 64μcd
Luminous Intensity 64 mcd
Forward Voltage 5.5V
Power Dissipation 1.2W
Element Configuration Common Cathode
Min Supply Voltage 3V
Max Supply Voltage 5.5V
Interface Parallel, 8-Bit
Configuration 5 x 7
Number of Elements 140
Operating Supply Voltage 5V
Depth 11.43mm
Number of Functions 4
Subcategory LED Displays
HTS Code 8531.20.00.40
Additional Feature TTL COMPATIBLE
Color Red
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Terminal Finish Tin/Copper (Sn/Cu)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e2
Size / Dimension 0.85Lx0.45W x 0.21 H 21.46mmx11.43mmx5.31mm
Series HCMS-29xx
Published 2011
Physical
Number of Pins 12
Package / Case DIP
Mount Through Hole
Contact Plating Copper, Tin
Supply Chain
Factory Lead Time 16 Weeks
