HCMS-2961
RoHS
RoHS compliant
RoHS compliantPackage DIP
Category Optoelectronics / Display Modules - LED Dot Matrix and Cluster
Description
LED DISPLAY 5X7 4CHAR 5MM YLW
PDF
/
Buying Options
Total Price: USD $11.24
Unit Price: USD $11.2404
≥1 USD $11.2404
≥10 USD $9.22355
≥100 USD $8.93475
≥500 USD $8.6469
≥1000 USD $8.3581
Inventory: 8602
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Character Height 5.08mm
Viewing Area (height) 4.57mm
Height 5.334mm
Technical
Dominant Wavelength 585 nm
Number of Characters 4
Power Consumption 1.2W
Wavelength - Peak 583 nm
Luminous Intensity 64 μcd
Forward Voltage 5V
Forward Current 10mA
Power Dissipation 1.2W
Element Configuration Common Cathode
Min Supply Voltage 3V
Max Supply Voltage 5.5V
Interface Parallel, 8-Bit
Configuration 5 x 7
Number of Elements 140
Operating Supply Voltage 5V
Depth 11.43mm
Number of Functions 4
Voltage - Rated DC 5V
Subcategory LED Displays
HTS Code 8531.20.00.40
Additional Feature TTL COMPATIBLE
Color Yellow
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Terminal Finish Tin/Copper (Sn/Cu)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e2
Size / Dimension 0.85Lx0.45W x 0.21 H 21.46mmx11.43mmx5.31mm
Series HCMS-29xx
Physical
Number of Pins 12
Package / Case DIP
Mount Through Hole
Supply Chain
Factory Lead Time 5 Weeks
