HCMS-2923
RoHS
RoHS compliant
RoHS compliantPackage DIP
Category Optoelectronics / Display Modules - LED Dot Matrix and Cluster
Description
LED DISPL 5X7 2X8CHAR 3.8MM GRN
PDF
/
Inventory: /
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Character Height 3.81mm
Viewing Area (height) 3.71mm
Height 5.08mm
Technical
Dominant Wavelength 574 nm
Number of Characters 16
Power Consumption 4.8W
Wavelength - Peak 568 nm
Millicandela Rating 114μcd
Luminous Intensity 114 mcd
Forward Voltage 5V
Forward Current 10mA
Power Dissipation 4.8W
Element Configuration Common Cathode
Min Supply Voltage 3V
Max Supply Voltage 5.5V
Interface Parallel, 8-Bit
Configuration 5 x 7
Number of Elements 560
Operating Supply Voltage 5V
Depth 19.81mm
Number of Functions 16
Voltage - Rated DC 5V
Subcategory LED Displays
HTS Code 8531.20.00.40
Additional Feature TTL COMPATIBLE
Color Green
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Terminal Finish Tin/Copper (Sn/Cu)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e2
Size / Dimension 1.40Lx0.78W x 0.20 H 35.56mmx19.81mmx5.08mm
Series HCMS-29xx
Physical
Number of Pins 15
Package / Case DIP
Mount Through Hole
Contact Plating Copper, Tin
Supply Chain
Factory Lead Time 16 Weeks
