HCMS-2914

Broadcom Limited
RoHS
RoHS RoHS compliant
Package DIP
Category Optoelectronics / Display Modules - LED Dot Matrix and Cluster
Description Alphanumeric Displays Panel 8DIGIT 280LED Orange 14-Pin DIP
PDF
/
Buying Options
Total Price: USD $83.62
Unit Price: USD $83.621227
≥1 USD $83.621227
≥200 USD $33.366041
≥500 USD $32.251389
≥1000 USD $31.699971
Inventory: 1261
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 16 Weeks

Physical

Mount Through Hole
Package / Case DIP
Number of Pins 14

Technical

Series HCMS-29xx
Size / Dimension 1.40Lx0.40W x 0.20 H 35.56mmx10.16mmx5.08mm
JESD-609 Code e2
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Terminal Finish Tin/Copper (Sn/Cu)
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Color Orange
Additional Feature TTL COMPATIBLE
HTS Code 8531.20.00.40
Subcategory LED Displays
Voltage - Rated DC 5V
Number of Functions 8
Depth 10.16mm
Number of Elements 280
Configuration 5 x 7
Interface Serial
Max Supply Voltage 5.5V
Min Supply Voltage 3V
Element Configuration Common Cathode
Power Dissipation 2.4W
Forward Voltage 5V
Luminous Intensity 64 μcd
Wavelength - Peak 600 nm
Number of Characters 8
Dominant Wavelength 602 nm

Dimensions

Height 5.08mm
Viewing Area (height) 3.71mm
Character Height 3.81mm

Compliance

RoHS Status ROHS3 Compliant
Lead Free Lead Free
