HCMS-2912
RoHS
RoHS compliant
RoHS compliantPackage DIP
Category Optoelectronics / Display Modules - LED Dot Matrix and Cluster
Description
LED DISPLAY 5X7 8CHAR 3.8MM HER
PDF
/
Buying Options
Total Price: USD $37.83
Unit Price: USD $37.8312
≥1 USD $37.8312
≥10 USD $29.55744
≥100 USD $28.079594
Inventory: 271
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Character Height 3.81mm
Viewing Area (height) 3.71mm
Height 5.08mm
Technical
Dominant Wavelength 626 nm
Number of Characters 8
Power Consumption 2.4W
Wavelength - Peak 635 nm
Luminous Intensity 64 μcd
Forward Voltage 5V
Forward Current 264mA
Power Dissipation 2.4W
Element Configuration Common Cathode
Min Supply Voltage 3V
Max Supply Voltage 5.5V
Interface Serial
Configuration 5 x 7
Number of Elements 280
Operating Supply Voltage 5V
Depth 10.16mm
Number of Functions 8
Voltage - Rated DC 5V
Subcategory LED Displays
HTS Code 8531.20.00.40
Additional Feature TTL COMPATIBLE
Color Red
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Terminal Finish Tin/Copper (Sn/Cu)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e2
Size / Dimension 1.40Lx0.40W x 0.20 H 35.56mmx10.16mmx5.08mm
Series HCMS-29xx
Published 2011
Physical
Number of Pins 14
Package / Case DIP
Mount Through Hole
Supply Chain
Factory Lead Time 16 Weeks
