HCMS-2911
RoHS
RoHS compliant
RoHS compliantPackage DIP
Category Optoelectronics / Display Modules - LED Dot Matrix and Cluster
Description
LED DISPLAY 5X7 8CHAR 3.8MM YLW
PDF
/
Buying Options
Total Price: USD $37.81
Unit Price: USD $37.8136
≥1 USD $37.8136
≥10 USD $29.54336
≥100 USD $28.066544
Inventory: 193
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Character Height 3.81mm
Viewing Area (height) 3.71mm
Height 5.08mm
Technical
Dominant Wavelength 585 nm
Number of Characters 8
Display Type Dot Matrix
Power Consumption 2.4W
Wavelength - Peak 583 nm
Millicandela Rating 64μcd
Luminous Intensity 64 mcd
Forward Voltage 5V
Forward Current 10mA
Power Dissipation 2.4W
Element Configuration Common Cathode
Min Supply Voltage 3V
Max Supply Voltage 5.5V
Interface Parallel, 8-Bit
Configuration 5 x 7
Number of Elements 280
Operating Supply Voltage 5V
Depth 10.16mm
Number of Functions 8
Voltage - Rated DC 5V
Subcategory LED Displays
HTS Code 8531.20.00.40
Additional Feature TTL COMPATIBLE
Color Yellow
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Terminal Finish Tin/Copper (Sn/Cu)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e2
Size / Dimension 1.40Lx0.40W x 0.20 H 35.56mmx10.16mmx5.08mm
Series HCMS-29xx
Published 2011
Packaging Box
Physical
Number of Pins 14
Package / Case DIP
Mount Through Hole
Supply Chain
Factory Lead Time 16 Weeks
