LED CHARLIEPLEXED MATRIX - 9X16
PDF
/
Buying Options
Total Price: USD $18.23
Unit Price: USD $18.230929
≥1 USD $18.230929
≥200 USD $7.274779
≥500 USD $7.031892
≥1000 USD $6.911106
Inventory: 1149
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Length - Termination 0.122 inch
Plating Thickness FLASH inch
Height 2.286mm
Technical
Contact Pattern RECTANGULAR
Contact Finish Termination Gold (Au) - with Nickel (Ni) barrier
Dielectric Withstanding Voltage 500VAC V
Termination Type SOLDER
Interface I2C
Mating Contact Pitch 0.1 inch
Insulation Resistance 5000000000Ohm
Configuration 9 x 16
Contact Resistance 20mOhm
Contact Style SQ PIN-SKT
Rated Current (Signal) 3A
Body Depth 0.972 inch
Operating Temperature (Min) -55°C
Contact Gender MALE
Body Breadth 0.098 inch
Operating Temperature (Max) 105°C
PCB Contact Pattern RECTANGULAR
Number Of PCB Rows 1
Body Length or Diameter 0.1 inch
Reliability COMMERCIAL
Reference Standard UL
Number of Conductors ONE
Terminal Pitch 2.54mm
Total Number of Contacts 1
Contact Finish - Mating AU ON NI
Subcategory Headers and Edge Type Connectors
HTS Code 8536.69.40.40
Number of Rows 1
Color Green
Connector Type BOARD CONNECTOR
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e4
Size / Dimension 1.70Lx1.10W x 0.09 H 43.18mmx27.94mmx2.29mm
