TDSY3150
RoHS
RoHS compliant
RoHS compliantPackage 10-DIP (0.300, 7.62mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
Displays Module 1DIGIT 8LED Yellow CA 10-Pin DIP
PDF
/
Inventory: 4709
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Character Height 10mm
Viewing Area (height) 10mm
Height 12.7mm
Technical
Dominant Wavelength 594 nm
Common Pin Common Anode
Digit/Alpha Size 0.39 10.00mm
Number of Characters 1
Forward Voltage-Max 3V
Reverse Voltage 15V
Display Type 7-Segment
Wavelength - Peak 585nm
Millicandela Rating 3mcd
Luminous Intensity 450 μcd
Forward Current 20mA
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Viewing Angle 50 °
Voltage - Forward (Vf) (Typ) 2.4V
Power Dissipation 480mW
Element Configuration Common Anode
Number of Elements 8
Reach Compliance Code unknown
Depth 9.7mm
Number of Functions 1
Subcategory LED Displays
Color Yellow
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Terminal Finish Silver (Ag)
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e4
Size / Dimension 0.500 Hx0.372W x 0.252 D 12.60mmx9.45mmx6.40mm
Series TDS.31
Packaging Bulk
Physical
Number of Pins 10
Package / Case 10-DIP (0.300, 7.62mm)
Mount Through Hole
Supply Chain
Factory Lead Time 13 Weeks
