TDSR0760
RoHS
RoHS compliant
RoHS compliantPackage DIP
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
Displays Module 1DIGIT 8LED Red CC 10-Pin DIP Tube
PDF
/
Buying Options
Total Price: USD $1.81
Unit Price: USD $1.8128
≥1 USD $1.8128
≥10 USD $1.20648
≥100 USD $0.928136
≥500 USD $0.839027
≥1000 USD $0.721037
≥3000 USD $0.68171
Inventory: 515
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Physical
Mount Through Hole
Package / Case DIP
Number of Pins 10
Technical
Packaging Bulk
Published 2010
Size / Dimension 0.389 Hx0.291W x 0.236 D 9.90mmx7.40mmx6.00mm
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Terminal Finish Silver (Ag)
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Color Red
Subcategory LED Displays
Number of Functions 1
Depth 9.9mm
Number of Elements 8
Element Configuration Common Cathode
Power Dissipation 185mW
Voltage - Forward (Vf) (Typ) 1.8V
Forward Current 10mA
Current - Test 1mA
Luminous Intensity 2.2 mcd
Wavelength - Peak 650nm
Display Type 7-Segment
Reverse Voltage 5V
Forward Voltage-Max 2.4V
Number of Characters 1
Number of Segments 7
Digit/Alpha Size 0.28 7.00mm
Common Pin Common Cathode
Dominant Wavelength 640 nm
Character Width 6mm
Dimensions
Height 9.8806mm
Viewing Area (height) 7mm
Character Height 10mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
