TDSG1160-LM
RoHS
RoHS compliant
RoHS compliantPackage DIP
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
DISPLAY 7-SEG. 7MM GREEN C.C.4
PDF
/
Buying Options
Total Price: USD $1.69
Unit Price: USD $1.6896
≥1 USD $1.6896
≥10 USD $1.12464
≥100 USD $0.865216
≥500 USD $0.782144
≥1000 USD $0.672153
≥3000 USD $0.635492
Inventory: 530
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Physical
Mount Through Hole
Package / Case DIP
Number of Pins 10
Technical
Packaging Bulk
Published 2014
Series TDS.11
Size / Dimension 0.389 Hx0.291W x 0.236 D 9.90mmx7.40mmx6.00mm
JESD-609 Code e4
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Terminal Finish Silver (Ag)
Color Green
Subcategory LED Displays
Depth 7.4mm
Operating Temperature (Min) -40°C
Number of Elements 8
Element Configuration Common Cathode
Power Dissipation 400mW
Voltage - Forward (Vf) (Typ) 2.4V
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Forward Current 17mA
Current - Test 20mA
Luminous Intensity 9 mcd
Wavelength - Peak 565nm
Display Type 7-Segment
Reverse Voltage 15V
Forward Voltage-Max 3V
Number of Characters 1
Digit/Alpha Size 0.28 7.00mm
Common Pin Common Cathode
Dominant Wavelength 575 nm
Dimensions
Height 9.8806mm
Viewing Area (height) 7mm
Character Height 7mm
Compliance
REACH SVHC Unknown
RoHS Status ROHS3 Compliant
