XZFMDK05A
RoHS
RoHS compliant
RoHS compliantPackage 10-SMD, No Lead
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
DISPLAY LED 0.2" RED CA SMD
PDF
/
Buying Options
Total Price: USD $2.75
Unit Price: USD $2.7544
≥1 USD $2.7544
≥10 USD $1.83392
≥100 USD $1.411168
Inventory: 1273
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Package / Case 10-SMD, No Lead
Number of Pins 10
Technical
Packaging Cut Tape (CT)
Published 2011
Size / Dimension 0.394 Hx0.272W x 0.118 D 10.00mmx6.90mmx3.00mm
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 2A (4 Weeks)
ECCN Code EAR99
Color Red
Additional Feature IC COMPATIBLE
Number of Functions 1
Operating Temperature (Max) 85°C
Operating Temperature (Min) -40°C
Power Dissipation-Max 75mW
Voltage - Forward (Vf) (Typ) 1.85V
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Current - Test 10mA
Luminous Intensity 30 mcd
Wavelength - Peak 650nm
Forward Current-Max 0.03A
Display Type 7-Segment
Number of Characters 1
Digit/Alpha Size 0.20 5.08mm
Common Pin Common Anode
Dimensions
Height 10.0076mm
Compliance
RoHS Status ROHS3 Compliant
