XDMR14A
RoHS
RoHS compliant
RoHS compliantPackage 10-DIP (0.600, 15.24mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
DISPLAY LED 0.56" RED CA TH
PDF
/
Buying Options
Total Price: USD $2.05
Unit Price: USD $2.0504
≥1 USD $2.0504
Inventory: 48
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height 19.05mm
Technical
Common Pin Common Anode
Digit/Alpha Size 0.56 14.22mm
Number of Characters 1
Display Type 7-Segment
Forward Current-Max 0.03A
Wavelength - Peak 660nm
Luminous Intensity 34 mcd
Current - Test 10mA
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Voltage - Forward (Vf) (Typ) 1.8V
Power Dissipation-Max 75mW
Operating Temperature (Min) -40°C
Operating Temperature (Max) 85°C
Number of Functions 1
Additional Feature IC COMPATIBLE
Color Red
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Size / Dimension 0.750 Hx0.500W x 0.315 D 19.05mmx12.70mmx8.00mm
Published 2008
Packaging Tube
Physical
Package / Case 10-DIP (0.600, 15.24mm)
Supply Chain
Factory Lead Time 6 Weeks
