NSR161B
RoHS
/
Package 10-DIP (0.600, 15.24mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
LED 7SEG SIGND OV/FL DISP RED.6"
PDF
/
Inventory: 3968
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Package / Case 10-DIP (0.600, 15.24mm)
Technical
Packaging Tray
Published 2001
Size / Dimension 0.748 Hx0.492W x 0.315 D 19.00mmx12.50mmx8.00mm
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) Not Applicable
Color Red
HTS Code 8541.40.20.00
Number of Functions 0.5
Reach Compliance Code unknown
Operating Temperature (Max) 85°C
Operating Temperature (Min) -40°C
Configuration SEPARATE, 0.5 DIGIT WITH DECIMAL POINT
Power Dissipation-Max 60mW
Voltage - Forward (Vf) (Typ) 1.7V
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Current - Test 20mA
Luminous Intensity 12 mcd
Wavelength - Peak 660nm
Forward Current-Max 0.03A
Display Type 7-Segment
Number of Characters +/-1 (overflow)
Digit/Alpha Size 0.60 15.24mm
Common Pin Universal
Dimensions
Height 19mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
