NAR161B
RoHS
/
Package 10-DIP (0.600, 15.24mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
LED 7SEG DISP .60" RED CA BLACK
PDF
/
Inventory: 6351
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Viewing Area (height) 15.24mm
Height 18.9992mm
Technical
Common Pin Common Anode
Digit/Alpha Size 0.60 15.24mm
Number of Characters 1
Reverse Voltage 4V
Display Type 7-Segment
Wavelength - Peak 660nm
Luminous Intensity 12 mcd
Current - Test 20mA
Forward Current 30mA
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Voltage - Forward (Vf) (Typ) 1.7V
Power Dissipation 60mW
Element Configuration Common Anode
Number of Elements 8
Operating Temperature (Min) -40°C
Reach Compliance Code unknown
Depth 19mm
Number of Functions 1
Color Red
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Obsolete
Pbfree Code yes
Size / Dimension 0.748 Hx0.492W x 0.315 D 19.00mmx12.50mmx8.00mm
Published 2011
Packaging Tray
Physical
Number of Pins 10
Package / Case 10-DIP (0.600, 15.24mm)
Mount Through Hole
