RoHS
/
Package /
Category Optoelectronics / Display Modules - LED Character and Numeric
Description LED 7SEG DISP SNGL DIG SM CA RED
PDF
/
Inventory: 6534
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Technical

Packaging Tray
Size / Dimension 0.512 Hx0.378W x 0.276 D 13.00mmx9.60mmx7.00mm
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) Not Applicable
Color Red
Number of Functions 1
Reach Compliance Code unknown
Operating Temperature (Max) 85°C
Operating Temperature (Min) -30°C
Power Dissipation-Max 40mW
Voltage - Forward (Vf) (Typ) 1.7V
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Current - Test 10mA
Luminous Intensity 3.2 mcd
Wavelength - Peak 660nm
Forward Current-Max 0.02A
Display Type 7-Segment
Number of Characters 1
Digit/Alpha Size 0.40 10.16mm
Common Pin Common Anode

Dimensions

Height 13.0048mm

Compliance

RoHS Status RoHS Compliant
Lead Free Lead Free
