AAR101B
RoHS
/
Package 24-DIP (0.709, 18.00mm), 20 Leads
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
LED ALPHA-NUMERIC DISP 1" RED CA
PDF
/
Inventory: 5535
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Height 32.9946mm
Technical
Common Pin Common Anode
Digit/Alpha Size 1.00 25.40mm
Number of Characters 1
Display Type 16-Segment, Alphanumeric
Forward Current-Max 0.025A
Wavelength - Peak 660nm
Luminous Intensity 24 mcd
Current - Test 20mA
Voltage - Forward (Vf) (Typ) 3.4V
Power Dissipation-Max 100mW
Configuration COMPLEX
Operating Temperature (Min) -20°C
Operating Temperature (Max) 85°C
Reach Compliance Code unknown
Number of Functions 1
Color Red
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Obsolete
Pbfree Code yes
Size / Dimension 1.299 Hx0.898W x 0.354 D 33.00mmx22.80mmx9.00mm
Published 2001
Packaging Bulk
Physical
Package / Case 24-DIP (0.709, 18.00mm), 20 Leads
