LF-301VK
RoHS
RoHS compliant
RoHS compliantPackage 10-SMD, No Lead
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
DISPLAY 7SEG 8MM 1DGT RED CC SMD
PDF
/
Inventory: 8241
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Height 5.0038mm
Technical
Common Pin Common Cathode
Digit/Alpha Size 0.31 8.00mm
Number of Characters 1
Forward Voltage-Max 2.8V
Display Type 7-Segment
Wavelength - Peak 650nm
Luminous Intensity 10 mcd
Current - Test 10mA
Forward Current 15mA
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Element Configuration Common Cathode
Power Dissipation-Max 40mW
Operating Supply Voltage 2V
Number of Functions 1
Subcategory LED Displays
Color Red
Min Operating Temperature -25°C
Max Operating Temperature 75°C
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Moisture Sensitivity Level (MSL) 4 (72 Hours)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e1
Size / Dimension 0.433 Hx0.268W x 0.197 D 11.00mmx6.80mmx5.00mm
Published 2004
Packaging Cut Tape (CT)
Physical
Number of Pins 10
Package / Case 10-SMD, No Lead
