LB-602BA2 image
Favorite
LB-602BA2 image
Favorite
RoHS
RoHS RoHS compliant
Package 18-DIP
Category Optoelectronics / Display Modules - LED Character and Numeric
Description DISPLAY 7SEG 14.3MM 2DGT BLUE CA
PDF
/
Inventory: 9488
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant

Dimensions

Character Height 14.3mm
Height 18.9992mm

Technical

Character Width 8mm
Common Pin Common Anode
Digit/Alpha Size 0.56 14.30mm
Number of Segments 7
Number of Characters 2
Display Type 7-Segment
Wavelength - Peak 470nm
Millicandela Rating 56mcd
Luminous Intensity 56 mcd
Forward Current 10mA
Element Configuration Common Anode
Power Dissipation-Max 42mW
Operating Supply Voltage 3.6V
Number of Contacts 18
Number of Functions 2
Subcategory LED Displays
Color Blue
Min Operating Temperature -25°C
Max Operating Temperature 75°C
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e1
Size / Dimension 0.748 Hx0.984W x 0.315 D 19.00mmx25.00mmx8.00mm
Published 2008
Packaging Bulk

Physical

Package / Case 18-DIP
Mount Through Hole
