LAP-601VL image
Favorite
LAP-601VL image
Favorite
RoHS
RoHS RoHS compliant
Package 10-DIP (0.400, 10.16mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description DISPLAY NUM 14.6MM SGL RED CC
PDF
/
Buying Options
Total Price: USD $3.57
Unit Price: USD $3.5728
≥1 USD $3.5728
≥10 USD $2.52531
≥100 USD $2.06837
≥500 USD $1.743685
≥1000 USD $1.599382
≥3000 USD $1.533242
Inventory: 87
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Height 18.9992mm

Technical

Common Pin Common Cathode
Digit/Alpha Size 0.58 14.60mm
Number of Characters 1
Forward Voltage-Max 2.6V
Display Type 7-Segment
Forward Current-Max 0.02A
Wavelength - Peak 650nm
Luminous Intensity 36 mcd
Current - Test 10mA
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Voltage - Forward (Vf) (Typ) 1.9V
Power Dissipation-Max 448mW
Operating Temperature (Min) -25°C
Operating Temperature (Max) 75°C
Number of Functions 1
Subcategory LED Displays
Color Red
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Size / Dimension 0.748 Hx0.492W x 0.315 D 19.00mmx12.50mmx8.00mm
Series LAP-601 B/L
Published 2008
Packaging Bulk

Physical

Package / Case 10-DIP (0.400, 10.16mm)

Supply Chain

Factory Lead Time 12 Weeks
