LA-601VB
RoHS
RoHS compliant
RoHS compliantPackage 10-DIP (0.400, 10.16mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
DISPLAY 7SEG 14.6MM 1DGT RED CA
PDF
/
Buying Options
Total Price: USD $4.15
Unit Price: USD $4.1536
≥1 USD $4.1536
≥10 USD $2.93788
≥100 USD $2.40621
≥500 USD $2.028514
≥1000 USD $1.860628
≥3000 USD $1.78369
Inventory: 118
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Character Height 14.6mm
Viewing Area (height) 14.6mm
Height 18.9992mm
Technical
Character Width 8.3mm
Common Pin Common Anode
Digit/Alpha Size 0.58 14.60mm
Number of Segments 7
Number of Characters 1
Display Type 7-Segment
Wavelength - Peak 650nm
Luminous Intensity 14 mcd
Current - Test 10mA
Forward Current 20mA
Element Configuration Common Anode
Power Dissipation-Max 60mW
Operating Supply Voltage 2V
Number of Functions 1
Subcategory LED Displays
Color Red
Min Operating Temperature -25°C
Max Operating Temperature 75°C
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e1
Size / Dimension 0.748 Hx0.492W x 0.315 D 19.00mmx12.50mmx8.00mm
Published 2008
Packaging Bulk
Physical
Number of Pins 10
Package / Case 10-DIP (0.400, 10.16mm)
Mount Through Hole
Supply Chain
Factory Lead Time 10 Weeks
