LA-601EL image
Favorite
LA-601EL image
Favorite
RoHS
RoHS RoHS compliant
Package 10-DIP (0.400, 10.16mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description DISPLAY 7SEG 14.6MM 1DGT ORN CC
PDF
/
Buying Options
Total Price: USD $4.8
Unit Price: USD $4.79865
≥1 USD $4.79865
≥180 USD $1.915521
≥480 USD $1.851189
≥1020 USD $1.819679
Inventory: 1595
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant

Dimensions

Height 18.9992mm

Technical

Common Pin Common Cathode
Digit/Alpha Size 0.58 14.60mm
Number of Characters 1
Forward Voltage-Max 2.6V
Display Type 7-Segment
Wavelength - Peak 610nm
Luminous Intensity 90 mcd
Current - Test 10mA
Forward Current 25mA
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Element Configuration Common Cathode
Power Dissipation-Max 65mW
Operating Supply Voltage 2.05V
Number of Functions 1
Subcategory LED Displays
Color Orange
Min Operating Temperature -25°C
Max Operating Temperature 75°C
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e1
Size / Dimension 0.748 Hx0.492W x 0.315 D 19.00mmx12.50mmx8.00mm
Published 2008
Packaging Bulk

Physical

Package / Case 10-DIP (0.400, 10.16mm)

Supply Chain

Factory Lead Time 12 Weeks
